Wazuh dashboard
This Wazuh central component is a flexible and intuitive web interface for mining, analyzing, and visualizing security data. It provides out-of-the-box dashboards, allowing you to seamlessly navigate through the user interface. It also enables centralized management of the Wazuh manager and Wazuh agents, giving you full control from a single unified console.
The Wazuh dashboard shows security events, detected vulnerabilities, file integrity monitoring data, and configuration assessment results. It also shows cloud infrastructure monitoring events and regulatory compliance status. If you want to learn more about the Wazuh components, see the Getting started section.
Check the requirements below and choose an installation method to start installing the Wazuh dashboard.
Assisted installation: Install this component by running an assistant that automates the installation and configuration process.
Step-by-step installation: Install this component following detailed step-by-step instructions.
Requirements
Check the recommended operating systems and hardware requirements for the Wazuh dashboard installation. Make sure that your system environment meets all requirements and that you have root user privileges.
The Wazuh dashboard package opens no port. To open 443/TCP on a host with firewalld, run:
# firewall-cmd --permanent --add-port=443/tcp
# firewall-cmd --reload
Use another port number if you changed server.port. The Wazuh dashboard supports only systemd.
Recommended operating systems
The Wazuh dashboard requires a 64-bit Intel, AMD, or ARM Linux processor (x86_64/AMD64 or AARCH64/ARM64 architecture). Wazuh recommends the following operating system versions:
Amazon Linux 2023
Ubuntu 24.04, 26.04
Red Hat Enterprise Linux 9, 10
Hardware requirements
The Wazuh dashboard can be installed on a dedicated node or along with the Wazuh indexer.
Hardware requirements for each node:
Minimum
Recommended
Component
RAM (GB)
CPU (cores)
RAM (GB)
CPU (cores)
Wazuh dashboard
4
2
8
4
An all-in-one host runs the Wazuh indexer, Wazuh manager, and Wazuh dashboard together. For up to 25 agents, it needs 4 CPU cores and 8 GB of RAM, as in the Quickstart. Two or more Wazuh central components on one host need at least 8 GB of RAM and 4 CPU cores.
Required ports
The Wazuh dashboard uses the following ports.
Port |
From |
Purpose |
|---|---|---|
443/TCP |
Users' web browsers |
Wazuh web interface |
9200/TCP, outbound |
This Wazuh dashboard, to the Wazuh indexer nodes |
Wazuh indexer REST API |
55000/TCP, outbound |
This Wazuh dashboard, to the Wazuh manager master node |
Wazuh manager API |
